Short Stroke Cylinders P1OS-7P1M
Cylinder Ø12-100mm. max. 10 bar, Strokes up to 100mm. Single/double acting with and without guiding. Complete range of sensors.
Grippers
Robotic and automation compact precision gripping devices which offer a high clamping force to weight ratio and a repeatability of 0.03 mm. The range comprises three types of gripper, parallel in 5 sizes and angular 180o in 3 sizes.
Rodless Cylinders OSP
P1X-Cylinders Ø16-63mm, max 8 bar, strokes up to 4000mm/
Several standard variants of carriage units and a wide range of accessories. RC-Come with built in guided carriage.
3D Linear Units
Loads up to 100kg, 3 sizes, 8 bar. Stroke up to 800mm. Precision axis with integrated sensors and hydraulic cushioning. With intermediate shop, mechanical or programmable. Full range of accessories.
Rotary Actuators Kuroda PRN
9 sizes.
Single and double configuration. Precision aluminium extruded body and vanes. Output torques to 206 Nm at 6 bar.
IPS Structural Framing Systems
All aluminium metric profiles. Broad selection of metric connecting hardware and accessories for guards and machine frames.
Short Stroke Units and Rod Guidance
Short stroke units for combination with 3D components, Ø16 and 25mm. Rod- guidance for ISO cylinders. Ø32 – 100mm. Low cost suitable for automation.
Bellows Series 9109
Sizes 0 70 to 660mm, stroke 65 to 430 mm, upto triple convulsions, very high force and quick frictionless movement, maintenance free.
Viking
G1/8 and G1/4 directional valves, pneumatically or electrically operated, with 5/2, 5/3 variants and hand or foot operated version. Highly recommended for mobile applications. G1/8 size features a modular sub-base system.
I Sys H Series ISO Valve
A Complete Serial bus communication offering for all ISO Valves.
Extremely fast I/O backplane uses change-of-state (COS) connection to maximize performance.
UL, C-UL and CE certifications.
A communication module supports upto a maximum of 62 I/O modules and upto 250 inputs and 252 outputs.
Adex Valves
Sizes M3, M5 & 1/8” Compact body Large Flow, life more than 50 million cycles, Low Power Consumption of 0.6 watts, Multipin connector option, Inline or subbase Mounting version available 3/2, 5/2, 5/3 configuration available.
ISOMAX
High tech ceramic technology, size 1/8” to 1?2” long life cycle above 100 operations, switching without seal, stiction free, short response time, low sensitivity to air quality changes, suitable for vacuum or pressure applications.
Valvetronic
Global concept, associating pneumatic, electrical and electronic technologies, to allow the connection of a valve island to a central control system by means of multiwire cable or serial bus. Asi, Interbus S, Profibus DP, DeviceNet, Fipio –
Direct Acting Valves A Series:
Port size 1/89 to 1 1/4”, Direct operated solenoid, Suitable for Vacuum Operation, Precision Lapped Spool & Sleeve (Metal seal), Long service Life, Easy
replacement of solenoid unit.
Modular Interface PS1E
Omega rail mounting, common electrics & pnuematics simplify set up of these mini valves. Pnue- matic indicators, LEDs, manual overrides facilitate easy main- tenance. Available in 3/2 & 4/2 version, monostable & bistable, instant Ø4 & Ø6 mm connections.
Pneumatic Logic
A complete system that allows economic automation of simple machines. Poppet technology guarantees reliability whilst set-up is simplified by omega
rail mounting, modular, design, swivel connectors, instant connection and pressure test points.
Process Duty Buttons & Limit Switches
A full range of buttons with modular construction that combines an extensive range of operating heads with full range of pneumatic and electric switches. 3 ranges of limit switches will provide solutions for virtually any limit switch
application.
Control Accessories
A complete range of speed controllers, blockers, unloaders, optimisers, slow starters. Sizes from M5 to G1/2, instant connection or threaded connection. Monofunction or multifunction.
Heavy Duty Buttons and limit switches PM 320/520
M5, G1/8, G1/4 – G1/2, in-line mounting, Pressure 10 bar G1/4 in spool design with 3/2, 5/2 and 5/3 function. G3/8 and G 1?2 in poppet design 3/2 function.
Special solenoids on request.
Vacuum Systems
Over 100 suction cups in various materials and shapes. Wide array of generators from compact simple generators to multifunction units with built in latching, blow off, air conserving and electrical functions.
Full complement of accessories.
Flowstar
Sub-base valves conforming to VDMA 24563 and ISO 15407/1 size 18 and 26 mm. Suitable for food applications. Easy to assemble multiple manifold system.
Global FRL’s
3 body sizes, ports G1/8 to G2″, 10 bar. Complete modular system with filters, regulators, lubricators, filter/regulators, ball valves, manifolds, soft start /dump valves.
